2487M8 CARRIAGE BOLT - Bolted Track System

M8 x 12 Bolt Flathead

MATERIAL: Galvanised Steel

2487: M8 x 12 Bolt Flathead

Dimensions: M8 x 12 mm
Unit: Pieces (100)
Weight: 0.7kg / 100

2488M8 CARRIAGE NUT - Bolted Track System

M8 x 6.5 Flange Nut

MATERIAL: Galvanised Steel

2488: M8 x 6.5 Flange Nut

Dimensions: M8 x 6.5 mm
Unit: Pieces (10)
Weight: 0.06kg / 10

2600M8 CARRIAGE BOLT

2600

MATERIAL: Galvanised Steel

2600: M8 x 20 Bolt Domehead

To connect Vertical Angle 2060 to Horizontal 'C' Channel 2516

Dimensions: M8 x 20 mm
Unit: Pieces (100)
Weight: 1.7kg / 100

2602M8 WASHER

M8 Washer

MATERIAL: Galvanised Steel

2602: M8 Washer

Inside diameter: 8.4mm
Outside diameter: 15mm

Dimensions: M8
Unit: Pieces (100)
Weight: 0.22kg / 100

26103/8" x 1¼" BOLT

2610

MATERIAL: Galvanised Steel

2610: 3/8" x 1¼"

For use with Spring Castings - UNC Thread

Dimensions: 9.525 x 31.75 mm
Unit: Pieces (100)
Weight: 2.2kg / 100

2611M6 TRACK BOLT

2611

MATERIAL: Galvanised Steel

2611: M6 x 16 Bolt

For use with 2" and 3" tracks

Dimensions: M6 x 16 mm
Unit: Pieces (100)
Weight: 0.4kg / 100

2612M6 TRACK NUT

2612

MATERIAL: Galvanised Steel

2612: M6 Serrated Flange Nut

For use with 2" and 3" tracks

Dimensions: M6 x 6.5 mm
Unit: Pieces (100)
Weight: 0.3kg / 100

26133/8" x 5/8" BOLT

2613 Bolt 3.8 x 5.8 UNC Thread

MATERIAL: Galvanised Steel

2613: 3/8" x 5/8" - UNC Thread

For use with Spring Castings

Dimensions: 9.525 x 15.875 mm
Unit: Pieces (100)
Weight: 2.0kg / 100

2620M6 CARRIAGE BOLT

M6 Carraige Bolt

MATERIAL: Galvanised Steel

2620: M6 x 16 Carraige Bolt

Dimensions: M6 x 16 mm
Unit: Pieces (100)
Weight: 0.5kg / 100

26243/8" NUT

2624

MATERIAL: Galvanised Steel

2624: 3/8" Nut - UNC Thread

For use with Spring Castings

Dimensions: 3/8" x 6.3575 mm
Unit: Pieces (100)
Weight: 0.30kg / 100

2630PANEL FIXINGS

2630

MATERIAL: Galvanised Steel

Galvanised Self Tapping Fastener
6.3 x 25mm H x HD

Dimensions: 6.3 x 25 x 14 mm
Unit: Pieces (100)
Weight: 0.8kg / 100

2631PANEL FIXINGS

2631 Panoramic Panel Fixing 6.3 x 11mm

MATERIAL: Galvanised Steel

Galvanised Self Tapping Fastener for Panoramic Doors
6.3 x 11mm H x HD

Dimensions: 6.3 x 11 x 14 mm
Unit: Pieces (100)
Weight: 0.6kg / 100

2632M10 x 25mm BOLT

M10 x 25mm Bolt

MATERIAL: Galvanised Steel

2632: M10 x 25mm Bolt

Dimensions: M10 x 25 mm
Unit: Pieces (100)
Weight: 2.5kg / 100

2633M10 FLANGE NUT

M10 Flange Nut

MATERIAL: Galvanised Steel

2633: M10 Flange Nut

Dimensions: M10 x 6 mm
Unit: Pieces (100)
Weight: 1.2kg / 100

2638M8 x 35MM BOLT

M8 x 35mm Bolt

MATERIAL: Galvanised Steel

2638: For Steelwork Fixing

Dimensions: M8 x 35 mm
Unit: Pieces (100)
Weight: 1.6kg / 100

26403MM CABLE CLAMP

2640 2641

MATERIAL: Galvanised Steel

2640: 3mm

Dimensions: 21 x 20 x 10 mm
Unit: Pieces (10)
Weight: 0.08kg / 10

26414/5MM CABLE CLAMP

2640 2641

MATERIAL: Galvanised Steel

2641: 4/5mm

Dimensions: 23 x 24 x 11 mm
Unit: Pieces (10)
Weight: 0.13kg / 10

2642PARO CLAMP PLATE

2642

MATERIAL: Galvanised Steel

2642: Single Paro Clamp Plate

M8 x 20mm Bolt installed

For use with Horizontal 'C' Channel 2516

Including M8 Nut

Dimensions: 53 x 25 x 25 mm
Unit: Piece (1)
Weight: 0.05kg

2643DOUBLE PARO CLAMP PLATE

2643

MATERIAL: Galvanised Steel

2643: Double Paro Clamp Plate

2no M8 x 20mm Bolts installed

For use with Horizontal 'C' Channel 2516

Including M8 Nuts

Dimensions: 113 x 43 x 25 mm
Unit: Piece (1)
Weight: 0.15kg

2645M8 FLANGE NUT

M8 Flange Nut

MATERIAL: Galvanised Steel

2645: M8 Flange Nut

For use with Paro Clamps

Dimensions: M8 x 6 mm
Unit: Pieces (10)
Weight: 0.07kg / 10

2646M10 x 50MM BOLT

M10 x 50 Bolt

MATERIAL: Galvanised Steel

2646: For Steelwork Fixing

Dimensions: M10 x 50 mm
Unit: Pieces (10)
Weight: 3.5kg / 10

2647M10 WASHER

M10 Washer

MATERIAL: Galvanised Steel

2646: For Steelwork Fixing

Dimension: M10
Unit: Pieces (10)
Weight: 0.02kg / 10


All sections in Track Assembly : Vertical Angles , Horizontal Track , Vertical Track , Horizontal 'C' Channel , Low Headroom Tracks , Spring Bumpers , Sheaves / Pulley , Track Clips and Plates , Track Side Seal , Installation Angle , Fixings / Bolts .
